MIL-DTL-85667/12A
REQUIREMENTS:
Application criteria. The sleeve bolt shall be used to provide a precision net fit or controlled
interference fit. The sleeve bolts shall be used in accordance with the limitations of MIL-B-85667/1.
The sleeve bolts shall not be degreased and cetyl alcohol shall not be removed before installation.
Companion and accessory parts. Nuts in accordance with MIL-N-85729 shall be used with the
sleeve bolts.
Oversize bolts. First and second oversize sleeve bolts may replace MIL-DTL-85667/12 sleeve bolts
for first and second repair operations.
Installation. Installation shall be in accordance with MIL-HDBK-271/104.
Material. Pin material shall be titanium 6AL-4L in accordance with AMS 4967 or AMS 4928
(UNS R56400).
Sleeve material shall be corrosion resistant steel, AISI 304 (UNS S30400), in accordance
with MIL-T-8504 (chemistry only) or ASTM A269 (chemistry only).
Heat treatment. Pin shall be heat treated in accordance with SAE-AMS-H-81200 to 95 Ksi Fsu
minimum and 160 Ksi Ftu minimum.
Surface texture. Surface texture shall be 32 microinches Ra in accordance with ASME B46.1.
Coatings or surface treatment. Pin shall be dry-film lubricated in accordance with MIL-PRF-46010,
Type I, .0003 / .0005 thick.
Sleeve - None.
Lubricants. .0001 inch overspray allowed on head and threads. After application of dry lubrication,
the pin outside diameter and sleeve inside diameter shall be lubricated with cetyl alcohol in
accordance with MIL-L-87132 or equivalent.
Unless otherwise specified, all dimensions are in inches. Tolerances: Decimals ± .010, angles +2°.
Example of military part number:
M85667/12 - 12 - 34
Grip length dash number in sixteenths of an inch.
(Stamp on threaded end.)
`-' designates basic shank diameter: X designates 1st
oversize, Y designates 2nd oversize. (Ink stamp on
sleeve when applicable.)
Diameter dash numbers in sixteenths of an inch.
Basic specification sheet number.
