MIL-DTL-85667/5B
REQUIREMENTS:
Application criteria. The sleeve bolt shall be used to provide a precision net fit or controlled interference fit.
The sleeve bolts shall be used in accordance with the limitation of MIL-B-85667/1. The sleeve bolts shall not be
degreased and cetyl alcohol shall not be removed before installation.
Companion and accessory parts. Nuts in accordance with MIL-N-85729 shall be used with the sleeve bolts.
Oversize bolts. First and second oversize bolts may replace MIL-DTL-85667/5 sleeve for first and second repair
operations.
Installation. Installation shall be in accordance with MIL-HDBK-271/104.
Material. Pin material shall be titanium 6AL-4V in accordance with AMS 4967 and AMS 4928 (UNS R56400).
Sleeve material shall be corrosion resistant steel, AISI 304 (UNS S30400), in accordance with
MIL-T-8504 (chemistry only) or ASTM A269 (chemistry only).
Heat treatment. Pin shall be heat treated in accordance with SAE-AMS-H-81200 and shall develop 160 ksi
Tensile strength and 95 ksi shear strength.
Surface texture. Surface texture shall be 32 microinches Ra in accordance with ASME B46.1.
Coatings or surface treatment. Pin shall be dry-film lubricated in accordance with MIL-PRF-46010, Type I,
.0003/.0005 thick.
Sleeve None.
Lubricants. .0001 inch overspray allowed on head and threads. After application of dry lubrication, the pin
outside diameter and sleeve inside diameter shall be lubricated with cetyl alcohol in accordance with
MIL-L-87132 or equivalent.
Unless otherwise specified, all dimensions are inches. Tolerances: Decimals ± .010, angles ± 2º.
Example of military part number:
M85667/5 - 12 X 34
Grip length dash number in sixteenths of an inch.
(Stamp on threaded end.)
` ` designates basic shank diameter: X designates 1st oversize, Y designates
2nd oversize. (Ink stamp on sleeve when applicable.)
Diameter dash numbers in sixteenths of an inch.
Basic specification sheet number.
10
